MODEL TL-5930/F

For Utility Metering Applications


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 5 mA TO 2V 19 Ah
Rated voltage 3.6V
Maximum continuous current 230mA
Maximum pulse current capability 500mA
Rated 1 sec. pulse capability (to 3V) 100mA
Weight 105g (3.7 oz.)
Operating temperature range -55'C to +85'C
U.L. Component recognition MH 12193


Connector Type
Housing Molex 50-57-9402
Contacts Molex 16-02-0086



Note: Any representations in this website concerning performance, are for informational purposes only
and are not construed as warranties either expressed or implied, of future performance.
