(Typical Values @+25'C for batteries
stored for one year or less)
Nominal capacity @ 0.3mA TO 2V
0.4Ah
Rated voltage
3.6V
Weight
5.3g (0.187 oz.)
Volume
1.2 cc
Operating temperature range
-55'C to +75'C
U.L. Component recognition MH
12193
AVAILABLE TERMINATION
SUFFIX- /P
TINNED NIKEL PINS
