MODEL TL-5104

International size reference :AA ER14505


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 2mA TO 2V 2.1Ah
Rated voltage 3.6V
Weight 17.4g (0.615 oz.)
Volume 8cc
Operating temperature range -55'C to +85'C
U.L. Component recognition MH 12193




AVAILABLE TERMINATIONS
SUFFIX- /S STANDARD
SUFFIX- /P AXIAL PINS
SUFFIX- /T SOLDER TABS
SUFFIX- /PT2 RADIAL PINS
SUFFIX- /PT/TP POLARIZED TABS



Note: Any representations in this website concerning performance, are for informational purposes only and are not
construed as warranties either expressed or implied, of future performance.
