MODEL TL-4955

International size reference : 2/3AA, ER14335


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 0.7mA, TO 2V 1.65Ah
Rated voltage 3.6V
Rated 1 sec. pulse capability 25mA
Weight 11.8g (0.416oz.)
Volume 5.7 cc
Operating temperature range -55'C to +85'C
U.L. Component recognition MH 12193


AVAILABLE TERMINATIONS
SUFFIX- /S STANDARD
SUFFIX- /P AXIAL PINS
SUFFIX- /T SOLDER TABS
SUFFIX- /PT2 RADIAL PINS
SUFFIX- /PT/TP POLARIZED TABS



Note: Any representations in this website concerning performance, are for informational purposes only and are not
construed as warranties either expressed or implied, of future performance.
