(Typical Values @+25'C for batteries
stored for one year or less)
Nominal capacity @ 2mA TO 2V
8.5Ah
Rated voltage
3.6V
Rated 1 sec. pulse capability
45mA
Weight
50.5g (1.78oz.)
Volume
26 cc
Operating temperature range
-55'C to +85'C
U.L. Component recognition MH
12193
AVAILABLE TERMINATIONS
SUFFIX- /S
STANDARD
SUFFIX- /T
SOLDER TABS
Note: Any representations
in this website concerning performance, are for informational purposes only and
are not construed as warranties either expressed or implied, of future
performance.
