MODEL TL-4903

International size reference : AA, ER14505


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 1mA, TO 2V 2.4Ah
Rated voltage 3.6V
Rated 1 sec. pulse capability 40mA
Weight 17.6g (0.62oz.)
Volume 8cc
Operating temperature range -55'C to +85'C
U.L. Component recognition MH 12193


AVAILABLE TERMINATIONS
SUFFIX- /S STANDARD
SUFFIX- /P AXIAL PINS
SUFFIX- /T SOLDER TABS
SUFFIX- /PT2 RADIAL PINS
SUFFIX- /PT/TP POLARIZED TABS



Note: Any representations in this website concerning performance, are for informational purposes only and are not
construed as warranties either expressed or implied, of future performance.
