MODEL TL-2100
International size reference : AA, ER14505
TECHNICAL DATA
(Typical Values @+25'C for batteries
stored for one year or less)
| Nominal capacity @ 2mA TO 2V |
|
2.1Ah |
| Rated voltage |
|
3.6V |
| Maximum continuous current |
|
100mA |
| Maximum pulse current capability |
|
200mA |
| Rated 1 sec. pulse capability (to 3V) |
|
40mA |
| Weight |
|
17.4g (0.615oz.) |
| Operating temperature range |
|
-55'C to +85'C |
U.L. Component recognition MH
12193
 |
|
AVAILABLE TERMINATIONS
| SUFFIX- /S |
STANDARD |
| SUFFIX- /P |
AXIAL PINS |
| SUFFIX- /T |
SOLDER TABS |
| SUFFIX- /PT2 |
RADIAL PINS |
| SUFFIX- /PT/TP |
POLARIZED TABS | |
|
|
|
|
|
 |
|
 |
|
|
|
|
|
Note: Any representations in this website concerning performance, are for
informational purposes only and are not
construed as warranties either
expressed or implied, of future performance.
